The Squaredrop ‘Dash’


Get your Smidge Spec & Price List

Sign up below and we will send you the price list for our Teardrop and Squaredrop range.

The ‘baby’ of the range in our squaredrop campers, still provides a level up from a tent! Carry your equipment around with you easily, with a large space to fill and move around in. Made of the highest quality materials, in order to accompany the high calibre adventures!

This entry level camper provides all the luxuries you need when first starting out, with a hassle free set up without the worry of canvas or tent. Completely customizable and allows you to control your trips.

FEATURES

  • Fully welded galvanised steel chassis

  • Marine plywood floor with waterproofing membrane

  • lightweight vinyl coated plywood

  • Hard wearing ABS edge tape

  • Fibreglass exterior and interior panel

  • Walls and roof fully insulated

  • One piece fibreglass roof – no joins

  • Lightweight, strong composite walls

  • Kitchen drawer

  • Block out curtain

  • Single access door with lockable security door

  • Single awning light above door

  • High density foam mattress

SPECIFICATIONS

  • Body length - 2.8m

  • Overall length (including draw bar) - 4.96m

  • Body width - 1.7m

  • Overall width - 2.1m

  • Height - 2m

  • Weight - 800kg

  • Ball weight - 80kg

  • Gvm - 1050kg

  • Payload (how much you can safely add) - 250kg

  • Bed size - 1530 x 2020mm

  • Water capacity - 2 x 20L

UTILITIES AND EQUIPMENT

  • Low volt consumption LED lights

  • Rebound leaf spring suspension suitable for off road use

  • USB point in bed area and in kitchen

  • 120amp/Hr AGM battery

  • Master power cut off switch

  • Jerry can water tank

  • Hand pump tap

  • Bluetooth speaker

  • Wind down stabilizer legs

  • Hand brake

  • Jockey wheel

  • Trailer brakes
