The Teardrop ‘Dram’


Get your Smidge Spec & Price List

Sign up below and we will send you the price list for our Teardrop and Squaredrop range.

The top of the range model, effectively becoming a house on wheels! Equipped with every additional extra that can be fitted to a Smidge Teardrop, you won’t be stuck with regret! With a sleek aerodynamic design, as well as a gorgeous look, the Dram oozes style.

FEATURES

  • Fully welded steel chassis

  • Bike rack fitted on drawer bar

  • Alloy wheels

  • Marine plywood floor with waterproofing membrane

  • European birch plywood cabinetry

  • Organic hard wax oil coating on interior surfaces

  • Fibreglass exterior panel

  • Walls and roof fully insulated

  • One piece fibreglass roof – no joins

  • Cutlery drawer

  • Lift out table

  • Roof hatch with blinds and flyscreen

  • Block out curtains

  • Access doors both sides with lockable security door

  • Awning lights on both sides

  • High density foam mattress folds up to make daybed/lounge

SPECIFICATIONS

  • Body length - 2.8m

  • Overall length (including draw bar) - 4.9m

  • Body width - 1.7m

  • Overall width - 2.1m

  • Height - 1.95m

  • Weight - 600kg

  • Ball weight - 50kg

  • Gvm - 1000kg

  • Payload (how much you can safely add) - 400kg

  • Bed size - 1530 x 1860mm

  • Water capacity - 80L

UTILITIES AND EQUIPMENT

  • Drop down stabilizer legs

  • Roof racks

  • Side mount awning

  • Slide out fridge freezer

  • Low volt consumption LED lights (dimmable)

  • Leaf spring suspension

  • Dual USB points on bed head and in kitchen

  • 120amp/Hr AGM battery

  • Master power cut off switch

  • Food grade water tank

  • 12v pump (10L/min)

  • 50L 12v fridge/ freezer

  • Heavy duty drawer slides used on fridge

  • Two burner stove with grill

  • Stainless steel sink

  • Bluetooth speaker

  • 12v fan

  • Hand brake

  • Fold up jockey wheel

  • Trailer brakes (Mechanical disk) for increased safety

  • 240v power inlet with RCD

  • 240v Power points in kitchen and bedroom area

  • 100w solar panel with MPPT regulator

  • Digital battery monitor
