The ‘Dram’ Squaredrop

Who said camping is roughing it? The Dram is the older sibling that has it all. Five star luxury that follows you everywhere you go. With all the options ticked there’s nothing else required in this compact classic that has it all.

Specifications

• Body length - 2.8m

• Overall length (including draw bar) - 4.96m

• Body width - 1.7m

• Overall width - 2.1m

• Height - 2.1m

• Weight - 850kg

• Ball weight - 90kg

• Gvm - 1200kg

• Payload (how much you can safely add) - 350kg

• Bed size - 1530 x 2020mm

• Water capacity - 80L

Features

• Fully welded galvinised steel chassis

• Storage box fitted on drawer bar

• Alloy wheels with offroad tyres

• Marine plywood floor with waterproofing membrane

• European birch plywood cabinetry

• Organic hard wax oil coating on interior surfaces

• Fibreglass interior and exterior panel

• Walls and roof fully insulated

• One piece fibreglass roof – no joins

• Cutlery drawer

• Lift out table

• Roof hatch with blinds and flyscreen

• Block out curtains

• Access doors both sides with lockable security door

• Awning lights on both sides

• High density foam mattress folds up to make daybed/lounge

Utilities and equipment

• Drop down stabilizer legs

• Roof racks

• Side mount awning

• Slide out fridge freezer

• Low volt consumption LED lights (dimmable)

• Rebound leaf spring suspension - suitable for offroad

• Dual USB points on bed head and in kitchen

• 120amp/Hr AGM battery

• Master power cut off switch

• Food grade water tank

• 12v pump (10L/min)

• 55L Waeco 12v fridge/ freezer

• Heavy duty drawer slides used on fridge

• Two burner stove with grill

• Stainless steel sink with glass lid

• Bluetooth radio with exterior speakers

• 12v fan

• Hand brake

• Fold up jockey wheel

• Trailer brakes (Mechanical disk) for increased safety

• 240v power inlet with RCD

• 240v Power points in kitchen and bedroom area

• 170w solar panel with MPPT regulator

• Digital battery monitor
